Description
Product Details:
Payment & Shipping Terms:
| Place of Origin: | China |
|---|---|
| Brand Name: | NUOYINGJIAYE |
| Certification: | CE,ATEX,SIL |
| Model Number: | NYRD-PB-E |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | $400 to $900 |
| Packaging Details: | Carton, 40cm x 30cm x 30cm |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T |
| Supply Ability: | 1000 pcs/per month |
| Accuracy: | 0.05%～0.1%F.S | Signal Output: | 4...20mA/HART/RS485/Modbus... |
|---|---|---|---|
| Display: | LCD | Material: | Stainless Steel |
| Measuring Range: | 0-40m | Power Supply: | 24V DC(Two-wire,Four-wire), 220V AC |
| Pressure Range: | 0.1-2.0MPa | Process Connection: | Flange, Thread, Etc. |
| Response Time: | 0.2s | Signal Frequency: | 26GHz |
| Temperature Range: | -40～+130℃, -40～+260℃ |
26G NYRD-PB Radar Working Principle
The radar horizontal antenna emits narrow microwave pulses, which are transmitted downward through the antenna. When the pulse wave touches the surface of the medium under test, it is reflected back and received again by the antenna system. This signal is transmitted to the electronic circuit section and automatically converted into a horizontal signal (due to the extremely fast propagation speed of the pulse, the time required for the electromagnetic wave to reach the target and return to the receiver after reflection is almost instantaneous).
Radar Level Meter Design Features
◎ The antenna is small in size, easy to install; non-contact radar, no wear and no pollution.
◎ Unaffected by corrosion, foam, water vapor, temperature and pressure changes.
◎ The beam angle is small and the energy is concentrated, which enhances the echo ability and helps to avoid interference.
◎ The measurement blind area is smaller, and it can also achieve good results for small tank measurement.
◎ High signal-to-noise ratio for better performance even under fluctuating conditions.
