| Place of Origin: | Xi'an,Shannxi,China |
|---|---|
| Brand Name: | NUOYINGJIAYE |
| Certification: | CE,ATEX,SIL |
| Model Number: | NYZK |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | $500~$750/pcs |
| Packaging Details: | Carton, 60cm x 30cm x 30cm |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T |
| Supply Ability: | 1000 pcs/per month |
| Indication Range: | Liquid Level, Boundary, Temperature, Pressure, Percentage | Display Mode: | 128x96 Dot Matrix Liquid Crystal Display |
|---|---|---|---|
| Accuracy: | ±0.1%F .S | Power Supply Voltage: | 24VDC,220VAC(optional) |
| Ambient Temperature: | -40℃〜+80°C | Relative Humidity: | ≤ 95%RH |
| Process Connection: | Bracket ,flange (optional) | Level Of Protection: | IP 66 |
| High Light: | Flange Radar Tank Level Indicator,Side Demonstrate Radar Tank Level Indicator,Tank Radar Level Gauge |
||
Tank Side Demonstrate NYZK Radar Tank Level Indicator Flange Flexible Application
NYZK Radar Tank Level Indicator Measuring principle
NYZK can display instrument (hereinafter referred to as "display instrumenf) is mainly used to output the auxiliary display of 4~20mA without digital display or with digital display but not easy to observe.Directly into the 4〜20mA loop, no additional power supply is required;This display instrument should be installed in the position by the tank easy to observe, convenient for nearby observation.Suitable for use with 4〜20mA output instruments;Using dot matrix liquid crystal display, can display different parameter names and units, the application is flexible;
NYZK Radar Tank Level Indicator Technical Parameter
| Indication range | Liquid level, boundary, temperature, pressure, percentage |
| Display mode | 128x96 Dot matrix liquid crystal display |
| Accuracy | ±0.1%F .S |
| Power Supply Voltage | 24VDC,220VAC(optional) |
| Ambient temperature | -40℃〜+80°C |
| Relative humidity | ≤ 95%RH |
| Process connection | Bracket ,flange (optional) |
| Level of protection | IP 66 |
| Explosion-proof grade | Exd IICT6(optional) |
※ Note: Products can be customized according to the specific requirements of users!
