Description
Product Details:
Payment & Shipping Terms:
| Place of Origin: | Xi'an, Shaanxi，China |
|---|---|
| Brand Name: | NUOYINGJIAYE |
| Certification: | ExdⅡCT6/ExmbⅡCT6 |
| Model Number: | NYCFQ-UL、NYCFQ-UK |
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | $450 to $1700 /pcs |
| Packaging Details: | Carton, 60cm×30cm×30cm |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 pcs/ pre month |
| Typical Application: | Liquid Level Measurement,etc. | Product Model: | NYCFQ-UL、NYCFQ-UK |
|---|---|---|---|
| Float Material: | F4、PP、304、PTFE(optional) | Rod Length: | 200~6000mm(Can Be Customized) |
| Ambient Temperature: | -40~+80℃ | Process Temperature: | -40~+130C |
| Process Pressure: | -0.1~2.0MPa | Process Connection: | Thread,flange(optional) |
| High Light: | Air Turbine Flow Meter 200mm,PTFE Turbine Flow Meter,Liquid Flow Meters 2.0MPa |
||
High Performance Air, Liquid Water Turbine Flow Meter
Description
High Performance Air, Liquid/Water Turbine Flow Meter (DN50) uses advanced differential technology, with isolation, shielding, filtering and other measures to overcome the similar products, poor shock resistance, small signal data disorder and other issues, and the use of a unique sensor packaging technology and protective measures to ensure product reliability.
Specification
| High Performance Air, Liquid/Water Turbine Flow Meter | |||
| Nominal Pass(mm) | 15, 20, 25, 40, 50, 65, 80, 125, 150, 200, 250, 300 | ||
| Instrument Material | 1Cr18Ni9Ti | ||
| Nominal Pressure(Mpa) | PN1.6Mpa; PN2.5Mpa; PN4.0Mpa | ||
| Measured Medium Temperature | -40℃ ~ +250℃; -40℃ ~ +350℃ | ||
| Environmental Conditions | Temperature | Humidity | Atmospheric Pressure |
| -10℃ ~ +55℃ | 5% to 90% | 86 ~ 106Kpa | |
| Accuracy | Liquid: ±0.5 for Indication; Gas or Vapor: ±1.0,±1.5 | ||
| Range Ratio | 1:10; 1:15 | ||
| Output Signal | 4-20mA Or Pulse Optional | ||
| Power Supply | Sensors | Transmitters | Live Display Type |
| 12V DC/24V DC | 24V DC | Instrument Comes With 3.2V Lithium Battery | |
| Installation Method | Flange Clamping or Integrated Flange Connection | ||
| Explosion-proof Grade | ExdllBT6 | ||
