Description
Water pH Meter Aquarium pH Sensor LCD Display ORP Transmitter Industrial Water pH Probe Tester
Product introduction
The product package contains1controller,1manual.
The controller is used for industrial PH/ORP and temperature measurement,such as fermentation,
drinking water,boiler water,sea water,aquaculture,aquarium,surface water,industrial sewage,urban
waste water,environmental monitoring,food production process,etc.
The controller can be panel,wall or pipe mounted.
The controller provides two current outputs.The maximum load is500Ω.
The controller provides 3 relays.It can pass though a maximum of 5A/250VAC or 5A/30VDC.
PH sensor technical parameter
| Model | NY-HB-I | NY-H650A |
| Measuring range | 0...14pH | 0...14pH |
| Slope | ≥96% | ≥96% |
| Temp measure range | 0.0...60.0℃ | 0.0...60.0℃ |
| Resolution | 0.01pH | 0.01pH |
| Accuracy | ±0.02pH | ±0.02pH |
| Install | Immersion type | Flow through type |
| Pressure range | 0-3bar | 0-3bar |
| Temperature sensor | PT1000 | PT1000 |
| Shell material | PPS | ABS |
| Thread | G3/4, NPT3/4 | M39*1.5 |
| Cable length | 5m | 5m |
| Protection grade | IP68 | IP68 |
Detailed Images
